TOGGLE SWITCH- PC TERMINALS
- Rating: DC 12V 15A / 24V 10A
- Contact R.: 50mΩ Max.
- Insulation R.: DC 500V 100MΩ Min.
- Dielectric strength: AC 1500V 1 minute.
- Electrical life: 50,000 make and break cycles at full load.
- Rubbr boot is included (screw nut: M12)
- Contact R.: 50mΩ Max.
- Insulation R.: DC 500V 100MΩ Min.
- Dielectric strength: AC 1500V 1 minute.
- Electrical life: 50,000 make and break cycles at full load.
- Rubbr boot is included (screw nut: M12)
Qty
Qty
Qty
Qty
Qty
-
Bulk No.
Type
Terminal
Switch
0402681 SPST 2P ON-OFF 0402682 SPST 2P (ON)-OFF 0402685 SPDT 3P ON OFF ON 0402686 SPDT 3P (ON) OFF ON 0402687 SPDT 3P (ON) OFF (ON) (ON) Momentary
